Camera
WDR (Wide Dynamic Range): > 120 dB
Image Sensor: 2.0 megapixel progressive scan CMOS
Signal System: PAL/NTSC
Effective Pixels: 1920(H)*1080(V)
Min. Illumination: Color: 0.005 Lux @ (F1.2, AGC ON), 0 Lux with IR
Shutter Time: PAL: 1/25 s to 1/50, 000 s
NTSC: 1/30 s to 1/50, 000 s
Slow Shutter: Max. 16 times
Lens: 2.7 mm to 13.5 mm motorized varifocal lens
Lens Mount: φ14
Adjustment Range: Pan: 0° to 360°, Tilt: 0° to 90°, Rotation: 0° to 360°
Day& Night: IR cut filter
Video Frame Rate: PAL:
1080p@25fpsNTSC:
1080p@30fpsSynchronization: Internal Synchronization
Lens
Horizontal Field of View: 102° to 31°
Menu
Image Mode: STD/HIGH-SAT
3D DNR (Digital Noise Reduction): Level 1 to 9
D/N Mode: Auto/Color/BW (Black and White)
BLC: Yes
AGC: High/Medium/Low/Off
HLC: Yes
WDR: Yes
Language: English
Function: Brightness, Sharpness, 3D DNR, Mirror, Smart IR
Interface
Switch Button: TVI/AHD/CVI/CVBS
Video Out: 1 HD analog output
General
Material: Front cover: Metal
Main body: Plastic
Bracket: Metal
Operation Condition: -40 °C to 60 °C (-40 °F to 140 °F), Humidity: 90% or less (non-condensation)
Power Supply: 12 VDC±25%
Power Consumption: Max. 7.7 W
Weather Proof: IP67
IR Range: Up to 70 m
Dimension: 84.5 mm × 92 mm × 255.1 mm (3.33" × 3.62" × 10")
