UNIFI
Dimensions 220 x 220 x 48.1 mm
Weight 700 g (24.7 oz), 830 g (29.3 oz) with Mounting Kits
Networking Interface (2) 10/100/1000 Ethernet Ports
Ports (2) Ethernet RJ45, (1) USB Type C
Buttons Reset
Antennas (2) 2.4G internal single band antennas, dual polarity (2) 5G internal single band antennas, dual polarity
Wi-Fi Standards 802.11a/b/g/n/ac/ac-wave2
Power Method PoE 802.3at
Power Supply PoE Injector 48VDC -0.5A Gigabit
Maximum Power Consumption 17W
Max TX Power 25 dBm
BSSID 4 Per Radio
Power Save Supported
Wireless Security WEP, WPA-PSK, WPA-Enterprise (WPA/WPA2, TKIP/AES)
Certifications CE, FCC, IC
Mounting Wall/Ceiling (Kits Included)
Operating Temperature -10 to 70° C (14 to 158° F)
Operating Humidity 5 to 95% Noncondensing
ADVANCED TRAFFIC MANAGEMENT
VLAN 802.1Q
Advanced QoS Per-User Rate Limiting
Guest Traffic Isolation Supported
WMM Supported
Concurrent Clients 500+
SUPPORTED DATA RATES (MBPS)
802.11a 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11n 6.5 Mbps to 450 Mbps (MCS0 - MCS23, HT 20/40)
802.11ac 6.5 Mbps to 1.7Gbps (MCS0 - MCS9 NSS1/2/3/4, VHT 20/40/80)
802.11b 1, 2, 5.5, 11 Mbps
802.11g 6, 9, 12, 18, 24, 36, 48, 54 Mbps
