Generale
Tipo di dispositivo
Adattatore di rete
Fattore di forma
Scheda plug-in - profilo basso
Tipo di interfacia (Bus)
PCI Express 3.0 x8 / PCI Express 3.0 x4
Revisione specifiche PCI
PCIe 3.0
Networking
Porte
25 Gigabit Ethernet x 2
Tecnologia di connessione
Cablato
Data Link Protocol
10 Gigabit Ethernet,25 Gigabit Ethernet
Velocità di trasferimento
25 Gbps
Prestazioni
Trasferimento dati bidirezionale:100 Gbps
Larghezza di banda per porta:
50 Gbps
CapacitÃ
Dimensione Jumbo frame:fino a 9,6 KB
Protocollo di gestione remota
SNMP
Indicatori di stato
Collegamento/attivitÃ
Caratteristiche
Supporto VLAN,supporto IPv6,modalità full-duplex,sconnessione TCP/IP,Quality of Service (QoS),supporto Jumbo Frame,supporto per IPv4,supporto per PXE,supporto LACP,supporto LLDP,Large Send Offload (LSO),Receive Side Scaling (RSS),supporto UEFI,TCP Segmentation Offload (TSO),tagging QoS,Extended Message-Signaled Interrupts (MSI-X),offloading UDP/IP,TCP/IP checksum offload,RDMA over Converged Ethernet (RoCE),Virtual Extensible LAN (VXLAN),Network Virtualization using Generic Routing Encapsulation (NVGRE),RDMA over Converged Ethernet (RoCE) v2
Standard di conformitÃ
IEEE 802.1Q,IEEE 802.1p,IEEE 802.3x,IEEE 802.3ad (LACP),IEEE 802.3ae,IEEE 802.1ab (LLDP),IEEE 802.3az,IEEE 802.1Qbb,IEEE 802.1Qaz,IEEE 802.1Qau,IEEE 802.1Qbg,IEEE 1588v2
Processore / Memory
Processore
1 x Mellanox Technologies Mellanox ConnectX-4 Lx
Espansione/connettivitÃ
Interfacce
2 x 25Gb Ethernet - SFP28
Miscellanea
Standard di conformitÃ
FCC certificato Classe A,CISPR 22 Classe A,ICES-003,EN55024,EN 60950-1,RoHS,ACA,cTUVus,BSMI Class A,VCCI Class A,EN 55022 Class A
Alimentazione
Potenza assorbita in esercizio
9.7 Watt
Software / Requisiti di sistema
Sistema operativo richiesto
SuSE Linux Enterprise Server 11,Microsoft Windows Server 2012,Oracle Solaris 11.1,Microsoft Windows Server 2012 R2,VMware ESXi 5.5,Ubuntu 14.04,Red Hat Enterprise Linux 7,Red Hat Enterprise Linux 6.6,Red Hat Enterprise Linux 7.1,Citrix XenServer 6.5,SuSE Linux Enterprise Server 12,Red Hat Enterprise Linux 6.7,Red Hat Enterprise Linux 7.2,VMware ESXi 6.0
Garanzia del produttore
Servizi e supporto
Garanzia limitata - 1 anno
Parametri ambientali
Temperatura min esercizio 5 °C
Temperatura max esercizio 60 °C
Umidità ambiente operativo 5 - 95% (senza condensa)
Informazioni sulla compatibilitÃ
Progettato per
HPE Apollo 4200 Gen10,4200 Gen10 336TB Archive Node with 25Gb NIC for Qumulo,4200 Gen10 for HPE Ezmeral Container Platform,4200 Gen10 Qumulo Archive Node,4200 Gen10 Qumulo Hybrid Node,4200 Gen9 for Google,4510 Gen10
HPE Nimble Storage dHCI Large Solution with HPE ProLiant DL380 Gen10,Medium Solution with HPE ProLiant DL360 Gen10,Small Solution with HPE ProLiant DL360 Gen10
HPE ProLiant DL180 Gen10,DL180 Gen10 Entry,DL180 Gen10 SMB,DL325 Gen10 Base,DL325 Gen10 Solution,DL360 Gen10 All Flash Server for Weka,DL360 Gen10 Compute Server for Cohesity DataPlatform,DL360 Gen10 Low,DL360 Gen10 Network Choice,DL360 Gen10 Performance for Cohesity DataPlatform,DL360 Gen10 SMB,DL360 Gen10 SMB Network Choice,DL360 Gen10 Solution,DL380 Gen10 All Flash Server for Datera,DL380 Gen10 Entry SMB,DL380 Gen10 for Cohesity DataPlatform,DL380 Gen10 for SAP HANA Compute Block,DL380 Gen10 Hybrid Server for Datera,DL380 Gen10 Network Choice,DL380 Gen10 Network Choice for CTERA,DL380 Gen10 NVMe All Flash Server for Datera,DL380 Gen10 Server for CTERA,DL380 Gen10 SMB,DL380 Gen10 SMB Networking Choice,DL380 Gen10 Solution,DL388 Gen10 Network Choice,DL560 Gen10 for SAP HANA Compute Block,DL580 Gen10 Base,DL580 Gen10 Entry,DL580 Gen10 Performance,DL580 Gen9 SAP HANA Scale-out Base Configuration,DL580 Gen9 SAP HANA Scale-up Base Configuration,DX380 Gen10,DX560 Gen10,ML350 Gen10 Base,ML350 Gen10 High Performance,ML350 Gen10 Performance,ML350 Gen10 SMB,ML350 Gen10 Solution,ML350 Gen10 Sub-Entry,XL170r Gen10 24TB Server for Cohesity DataPlatform,XL170r Gen10 36TB Add-on Server for Cohesity DataPlatform,XL190r Gen10 for HPE Ezmeral Container Platform,XL270d Gen10 for HPE Ezmeral Container Platform,XL450 Gen10
HPE SimpliVity 325 Gen10 Node,380 Gen10 G Node,380 Gen10 H Node,380 Gen10 Network Choice G Node,380 Gen10 Network Choice H Node,380 Gen10 Node
HPE StoreEasy 1660 Expanded Storage
